20hl Jacketed conical fermenter

Brief introduction
The jacketed conical fermenter is defined as a standard in the whole micro brewery area. Conical bottom is convenient for recycling the yeast after finishing the fermenting. Glycol jacket is used for cooling down the temperature of fermentation vessel. The temperature of fermenting can be evenly decreased while glycol water is running inside the jackets wrapped around the fermenter. Usually there are 2 or 3 section jacket on the cylinder of fermentation tank and 1 section on bottom. The jacketed conical fermenter can combine the fermentation and maturation processes into one vessel mounted with a carbonation stone.

20hl Jacketed conical fermenter


Quick overview of 20hl jacket conical fermenter
Capacity 20hl
Dimension Φ1560mmx3100mm
Body of Tank Dished head and conical bottom
Degree of Conical Bottom 60 degree or customizing
Location of Manway Top mounted manway
Dry Hopping Port Yes
Glycol Jacket Dual zone jackets on cylinder and cone
Heavy Duty Leg 4 pcs
Carbonation Device Optional

Main configuration of 20hl jacket conical fermenter
-Interior Shell: SUS304 full welded TH=3mm
-Exterior Shell:SUS304 full welded TH=2mm
-100% TIG welding with pure argon gas shield
-Interior Finish: Overall polishing to 0.2~0.4 μm without dead corner
-Insulation: Polyurethane; TH=80mm
-Glycol Jacket: Dimpled plate on cone and side
-Dished head and 60 degree cone bottom
-CIP arm with 360° coverage CIP spraying ball
-Mechanical relief valve 2 bar on CIP arm
-Shockproof pressure gauge on CIP arm
-Rotating racking arm and port on cone with butterfly valve
-Tri clamp discharge arm with butterfly valve
-Thermowell for high accuracy temperature sensor
-Dry hopping port with solid end cap
-Level tube for special request
-Carbonation port and stone for special request

Contact us immediately to get latest specification and price of 20hl Jacketed conical fermenter
