General Introduction of 2-Station Automatic Canning Machine
The 2-station automatic canning machine is a compact and efficient solution designed for small to medium-scale beverage canning operations, including beer, carbonated drinks, kombucha, cider, and other low-viscosity beverages.
The system integrates an infeed table, can flip rinsing unit, two filling stations, and one seaming station, enabling a smooth and continuous canning process from empty can feeding to finished sealed cans.
Empty cans are first transferred via the infeed table, ensuring stable and orderly can delivery. The can flip rinsing system inverts the cans and rinses the interior with water or sterilized air to remove dust and contaminants, improving hygiene before filling.
The machine is equipped with two automatic filling stations, offering precise and consistent filling control. Filling is typically based on level control, ensuring minimal oxygen pickup and stable fill volumes. The dual-station design improves throughput while maintaining compact equipment size.
After filling, cans are transferred to the single seaming station, where lids are accurately placed and double seamed to ensure airtight sealing and product safety. The seaming process is stable and reliable, meeting standard canning quality requirements.
With its automated operation, compact footprint, and user-friendly control, the 2-station auto canning machine is an ideal choice for craft producers seeking reliable performance, consistent quality, and efficient canning in limited space.
General Specifications of 2-Station Automatic Canning Machine
Tiantai provides comprehensive and customized solutions for a wide range of beverage production needs, which covers craft beer brewing systems, kombucha production equipment, carbonated beverage systems, fruit wine and cider equipment, as well as bottling and canning lines etc.
With years of industry experience, Tiantai is committed to delivering reliable equipment, practical system design, and professional technical support to customers worldwide. From individual tanks to complete turnkey projects, we help producers improve efficiency, product quality, and production stability.
If you are looking for a dependable equipment partner or planning a new beverage project, please feel free to contact me—we are ready to support your production goals with tailored solutions.
Derrick
Sales Manager
[email protected]
Tiantai Beer Equipment
The 2-station automatic canning machine is a compact and efficient solution designed for small to medium-scale beverage canning operations, including beer, carbonated drinks, kombucha, cider, and other low-viscosity beverages.
The system integrates an infeed table, can flip rinsing unit, two filling stations, and one seaming station, enabling a smooth and continuous canning process from empty can feeding to finished sealed cans.
Empty cans are first transferred via the infeed table, ensuring stable and orderly can delivery. The can flip rinsing system inverts the cans and rinses the interior with water or sterilized air to remove dust and contaminants, improving hygiene before filling.
The machine is equipped with two automatic filling stations, offering precise and consistent filling control. Filling is typically based on level control, ensuring minimal oxygen pickup and stable fill volumes. The dual-station design improves throughput while maintaining compact equipment size.
After filling, cans are transferred to the single seaming station, where lids are accurately placed and double seamed to ensure airtight sealing and product safety. The seaming process is stable and reliable, meeting standard canning quality requirements.
With its automated operation, compact footprint, and user-friendly control, the 2-station auto canning machine is an ideal choice for craft producers seeking reliable performance, consistent quality, and efficient canning in limited space.
General Specifications of 2-Station Automatic Canning Machine
| 2-Station Automatic Canning Machine | |
| Item | Specifications |
| Capacity | 800-1000PCS|2 STATION |
| Power | Singel Phase 110V-240VAC 50/60Hz is default |
| Power consumption | 900W |
| Main Material | AISI304, Aluminum Alloy and POM |
| Beer Source Requirement |
Temperature: 30.2 - 32F (-1 to 0C) Carbonation: 2.4 to 2.7 volumes CO2 (4.6 to 5.2 g/L CO2) Pressure：22psi（0.15MPa） Connection: 1.5" Tri-clamp |
| CO2 Pressure Requirement(CO2 Regulator) | 58-65 psi（0.4MPa-0.45Mpa） from plant system connected to canning system with 10mm OD barbed fitting |
| Air Pressure Requirement(Air Regulator） | 87-102 psi（0.6MPa-0.7Mpa） from plant system connected to canning system with 10mm OD barbed fitting |
| Seamer |
Cemented Carbide Panasonic Motor |
| Dissolved Oxygen) | ≤20ppb |
| Can type | It can be configured for nearly all standard can sizes! Change over between different can dimensions is a snap, requiring only a few simple tools and less than 30 minutes. |
| Rinse function | 3S/pc（adjustable） |
| Spray function | 2S/pc（adjustable） |
| Size:W*L*H | 1.44x 0.91x1.96M |
| Weight | 220KG |
| Packing Size L*W*H | 1.59x1.05x1.94M |
| Gross Weight | 360KG |
| Rotary Infeed Table | |
| Capacity | adjustable speed |
| Power | Singel Phase 110V-240VAC 50/60Hz is default |
| Power consumption | 500W |
| Main Material | AISI304, Aluminum Alloy and POM |
| Size:W*L*H | 0.6×0.65×1.16mm |
| Weight | 39KG |
| Packing Size （L*W*H) | 0.75×0.75×1.38M |
| Gross Weight | 80KG |
