Product Overview
The 4-Station Canning Filling Machine is a compact and efficient solution designed for small to medium-sized beverage producers. With four synchronized filling heads, it ensures fast, accurate, and hygienic can filling for beer, kombucha, soda, cider, and other carbonated or non-carbonated drinks.
Features:
[Option]Collection Table is optional
Advantages
Edited by Amanda
Sales manager of Tiantai brewtech
Email: [email protected]
The 4-Station Canning Filling Machine is a compact and efficient solution designed for small to medium-sized beverage producers. With four synchronized filling heads, it ensures fast, accurate, and hygienic can filling for beer, kombucha, soda, cider, and other carbonated or non-carbonated drinks.
Features:
♦ Beer canning filter dimension: 2.00×0.91×1.85M
♦ Rotary Infeed Table dimension: 0.9×0.9×1.25M
♦ Equipment Weight: 337KG
♦ Capacity: 1500-2000kg/hr: 1500-1800pcs/H(330ml) 495-594L/H; 1200-1500pcs/H(500ml) 600-750L/H
♦ Applicable cans type: Aluminum Can; Change over between different can dimensions is a snap, requiring only a few simple tools and less than 30 minutes.
♦ Power: According to user local power (standard 3 Phases 380V 50Hz)
♦ Power consumption: 2-3KW
♦ Main Material:AISI304, Aluminum Alloy and POM
♦ Beer Source Requirement
♦ Pressure: 0.12MPa
♦ Connection: 1.5" Tri-clamp
♦ Time setting way: Siemens PLC 200 smart and IEV3 Touch Screen
♦ Dissolved Oxygen: ≤50ppb
♦ Rinse function: 3S/pc (adjustable)
♦ Spray function: 2S/pc (adjustable)
[Option]Collection Table is optional
[Option]Labeling Machine is optional: Labeling Machine with Inkjet Coding;
[Option]Labeling Machine with Laser Coding
Advantages
✔ Cost-effective canning solution for small-scale production
✔ Consistent filling accuracy with minimal product loss
✔ Easy to integrate with seaming machine and packaging line
✔ Durable stainless steel construction for long service life
