30,000KL Annual Production Beer Factory
- Mar 29, 2030
- 185
- tiantai
Regional beer factory equipment consists of specialized machinery used for large-scale beer production, ensuring efficiency, consistency, and quality. Key components include the brewing system (mash tun, lauter tun, boil kettle, and whirlpool) for wort production, fermentation tanks for yeast activity, and bright beer tanks for maturation. Additional essential equipment includes cooling systems (heat exchangers and glycol chillers), CIP (Clean-in-Place) systems for sanitation, and packaging lines (bottling, canning, and kegging machines). Proper grain handling, pumps, and automation enhance production efficiency, making industrial breweries capable of high-volume beer manufacturing.
.jpg)
\\\2) General Configuration of 30,000KL Regional Beer Factory
3) Technical Basis of 30,000KL Regional Beer Factory
| Brew Length ( Cast Cold Out) | 15KL |
| Brew Batches per day | 6 batches |
| No. of working days | 330 |
| Cold wort collection per day | 20KL/60KL |
| Design based on brew plato | 15 |
| Maximum Output Plato | 19 |
| Minimum Output Plato | 12 |
| Malt spent grain thickness | 25cm - 38cm |
| Evaporation Rate: | 8% - 10% |
| Voltage Supply | 400V, 3 Phases,50HZ AC, 24V DC or customized |
| Water Supply Pressure | 2 - 6 bar |
| Steam Working Pressure | 2 bar |
| Air Source Pressure | 2 - 8 bar |
| Brewery Expanding |
Available |
4) Automation Level of 30,000KL Regional Beer Factory
To realize maximum automation level
Valves automation: pneumatic butterfly, pneumatic angle seat valve, pneumatic ratio angle seat valve
One click brewing to save manual operation and reducing error rates
Auto water mixing station for mashing or sparging
Auto wort cooling station to reach needed fermentation temperature
Auto brewing process, includes mashing, lautering, boiling and whirlpool
Auto discharge of spent grain
Auto mashing in before official brew day to save time and help streamline your mashing process
Auto vessel pre-heating to save time and improve brewing consistency.
Auto vessel flushing to maintain high level cleanliness and efficiency in brewing
Recipe storage for different types beer
Auto alarm protection
Auto security protection
Auto log archiving
Tiantai provides turnkey solutions on brewery equipment, if you have the plan to build an industrial brewery, I am at your disposal anytime.
