500L Nanobrewery System
Brief introduction
This 500L nanobrewery system what we are showing is exported to Korea, which is a combination of brewery and restaurant. 2-Vessel Brewhouse support to brew 1-2 batch a day. Fermentation unit includes 3x500L&2x1000L Fermenters and 1x500L&1x1000L Brite Tanks. Total fermentation capacity is 5000L. The annual beer output reaches 80000L-120000L.
(Please note total fermentation capacity CAN NOT be lower than 5000L according to Korea regulation)
Quick overview of 500L nano brewery system
Main configuration of 500L nano brewing system
Optional items: Beer filter, Keg filling system, Bottle filling system
Steam boiler, Water filter, Kegs
Customized requirement acceptable
Contact us immediately to get latest specification and price of 500L nano brewing system.
Brief introduction
This 500L nanobrewery system what we are showing is exported to Korea, which is a combination of brewery and restaurant. 2-Vessel Brewhouse support to brew 1-2 batch a day. Fermentation unit includes 3x500L&2x1000L Fermenters and 1x500L&1x1000L Brite Tanks. Total fermentation capacity is 5000L. The annual beer output reaches 80000L-120000L.
(Please note total fermentation capacity CAN NOT be lower than 5000L according to Korea regulation)
Quick overview of 500L nano brewery system
| Output/Brew | 500L |
| Brew/day | 1-2 |
| Output/Week | 1750L-2500L/week based on different configuration |
| Electric Supply | 3phase/380(220, 415,440…)v/50 (60)Hz |
| Heating Source | Steam (Optional Direct fire/Electric) |
| Area Request | >50M2 |
| Brewmaster | 1 |
| Mashing method | Infusion,multi-step infusion,decoction |
Main configuration of 500L nano brewing system
| Main brewing system | Components | Main specification |
|
Brewhouse unit |
500L Mash/lauter tun |
500L 25% head space Steam heating with insulation False bottom Spent grain outlet CIP, sight glass |
| 500L Kettle/whirlpool tun |
500L 40% head space Steam heating with insulation Steam condenser Wort outlet and trub outlet Tangential inlet |
|
| 1000L Hot Liquor tank |
1000L 20% head space, Steam heating with insulation Circulation port Recycle port Water outlet and trub outlet |
|
| 1000L Cold Liquor tank |
1000L 20% head space, Glycol cooling with insulation Circulation port Water outlet and trub outlet |
|
| Wort pump | 3T/hr, Sanitary | |
| Hot water pump | 3T/hr, Sanitary | |
| Cold water pump | 3T/hr, Sanitary | |
| Plate heat exchanger |
6m2 Single stage Connected with wort aeration device Disassemble |
|
| Work platform |
Disassemble, Adjustable |
|
|
Fermentation unit |
Fermentation tank |
3x500L+2x1000L 25% head space, Jacketed and insulated Conical bottom, Pressure valve, relief valve CO2 relief valve Coolant inlet and outlet Sample valve Topmanway Top, Dry Hopping Port CIP connections Wort inlet and yeast outlet Racking arm Temperature and pressure gauges |
| Maturation/Storage | Bright beer tank |
1x500L+1x1000L 20% head space, Jacketed and insulated Dished head&bottom Pressure valve, relief valve Site Glass level Carbonation stone assembly Sample valve Top manway Fill/drainage port CIP connections Temperature and pressure gauges Jacketed and single wall tanks |
|
Glycol cooling system |
500L Glycol cooling tank |
Thermowell Top manway CIP arm and spray ball 360 degree of coverage Thermowell |
| 2x3HP Chiller |
Second generation Freon R410A |
|
| Glycol water pump and piping | PPR Main Pipe and PEX Branch Pipe | |
|
Controlling unit |
Brewhouse and cellar control panel |
Temperature monitoring& controlling Pump on/off control VFD control |
| Cleaning unit | Portable CIP Pump | 3T/hr, Sanitary |
Optional items: Beer filter, Keg filling system, Bottle filling system
Steam boiler, Water filter, Kegs
Customized requirement acceptable
Contact us immediately to get latest specification and price of 500L nano brewing system.
