What is the key points of CIP system design in brewery?
- Aug 20, 2022
- 72
- tiantai
(1) The volume of the CIP storage tank should at least meet the requirements of the 10min working flow (volume meter) of the cleaning pump.
(2) If the CIP system needs a return pump to achieve the return circulation, the capacity of the return pump should be 20% to 30% higher than that of the output pump to prevent CIP liquid from accumulating in the system.
(3) The storage tank itself should have a cleaning device and a sewage device.
(4) The storage tank should be provided with overflow ports and exhaust holes, and the exhaust holes should be led to the outdoors.
(5) The CIP equipment group shall have observation corridors and good ventilation and lighting conditions.
(6) Storage tanks for acids, alkalis and other corrosive media shall have obvious safety signs and emergency signs.
(7) There should be liquid level gauges, thermometers and other measuring and display instruments in the tank to monitor the operation of the CIP system.
(8) Storage tanks such as acid, alkali and sterilant should be equipped with sampling valves, and the concentration should be checked regularly.
(9) It is recommended to use a double seat valve to avoid mixing of CIP fluids.
Edited by Alisa
Email:[email protected]
